Specification Sheet

Features and Benefits
Unsurpassed digital temperature sensing
provides unbeatable accuracy of 0.15°C / 0.27°F,
eliminating temperature swings
Use with 120, 208 or 240 Volt In-Wall Electric
Heaters and Baseboards, up to 2500 watts
On-screen heating power indicator verifies
power being used at-a-glance
Triac switching action provides 100% silent operation
Temperature lock limits minimum and maximum
setpoints
Push button controls
Two-wire design with non-polarized lead wires
assure easy installation for new construction
or replacement
Single Pole (2 wires)
General Information:
The TH401 electronic thermostat provides precise temperature control
using a proportional integral adaptive microprocessor. The slim design,
triac switching for silent operation, and push button access make this a
premium choice for a non-programmable thermostat. This single pole
(2 wire) model thermostat is recommended for 120, 208, and 240 volt
(line voltage) baseboard and in-wall fan heaters, and can be set for
15-second (baseboard) cycles, or 5-minute (fan heater) cycles. Setpoint
range: 40°F to 86°F (5°C to 30°C).
Architectural Information:
The electronic thermostat shall be UL and CSA Listed. The thermostat
shall have LED indication of status of heater. Switching means shall be
by “Triac switching action” to eliminate RF line noise. The control shall
be capable of switching loads of 10.4 amps at 240 VAC. Vented housing
shall be white and made of flame retardant high impact plastic with two
mounting screws provided. No batteries shall be required for operation.
Ordering Information: Available in white.
Part# Model# Description Wt./Lbs Case Qty
027418 72838 2 TH401 *Wholesale Boxed Electronic Non-Programmable .6 10
SP 10.4A 120V/208V/240V
*Available in December 2009
Carton Details
Product
DIMENSIONS
| 3.3”W x 5”H x 1.2”D
Single Carton
DIMENSIONS
| 3.75”W x 5.25” H x 2.75”D
Case
DIMENSIONS
| 14.57”W x 8.27”H x 6.3”D
The TH401
Electronic Non-Programmable Thermostat
PHONE 360.693.2505
FAX 360.694.8668
WEB www.cadetco.com
UPC Code
Best Choice Non-Programmable –
Smaller Areas
TH401
Now Available!
