Owner's Manual

TH114-A/AF-120S/240S/240D
3
ENGLISH
The TH114 non-programmable thermostat has three temperature control modes:
See page 9 on how to change the temperature control mode setting.
* Select models only; required for floor heating applications only.
About your thermostat
A mode:  controls the ambient air temperature
F mode:  controls the floor temperature using an external temperature sensor
AF mode:  controls the ambient air temperature
 maintains the floor temperature within desired limits using an external temperature
sensor
Supplied Parts
• One (1) thermostat
• Two (2) mounting screws
• Four (4) solderless connectors for copper wires
• One (1) floor sensor *
• One (1) flat-tip screwdriver *
