SmartSwitch Router User Reference Manual 61

Chapter 6: Packet-over-SONET Configuration Guide

To manage the working and protecting PoS interfaces, enter the following commands in

Configure mode:

Note:

You can only specify one option, lockoutprot, forced or manual, for a port. Also,

an option can be applied to either the working port or the protecting port, but not

both working and protecting ports at the same time.

To return the circuit to the working interface after the working interface becomes

available, enter the following commands in Configure mode:

Specifying Bit Error Rate Thresholds

If the bit error rate (BER) on the working line exceeds one of the configured thresholds, the

receiver automatically switches over to the protecting line.

BER is calculated with the following:

BER = errored bits received/total bits received

The default BER thresholds are:

• Signal degrade BER threshold of 10

-6

(1 out of 1,000,000 bits transmitted is in error).

Signal degrade is associated with a “soft” failure. Signal degrade is determined when

the BER exceeds the configured rate.

Prevent a working interface from switching to a

protecting port. This command can only be applied

to a port configured as a protecting port.

sonet set <port> protection-switch

lockoutprot

Force a switch to the specified port. This command

can be applied to either the working or protecting

port.

sonet set <port> protection-switch

forced

Manually switch the line to the specified port. This

command can be applied to either the working or

protecting port.

sonet set <port> protection-switch

manual

Enable automatic switchover from the protecting

interface to the working interface after the working

interface becomes available. This command can only

be applied to a protecting port.

sonet set <port> reverting

revertive|nonrevertive

Sets the number of minutes after the working

interface becomes available that automatic

switchover from the protecting interface to the

working interface takes place. The default value is 5

minutes.

sonet set <port> WTR-timer <minutes>
