Displaying ATM Port Information
50 SmartSwitch Router User Reference Manual
To display information about the port settings on an ATM port:
The following is an example of the information that is displayed with the command listed
above (for a PDH PHY interface):
• Port Type Shows the type of PHY interface for the port.
• Xmt Clock Source Shows the timing source for the port.
Local indicates the onboard clock oscillator as the
timing source.
Loop indicates the receiver input as the timing
source.
• Scramble Mode Shows the scramble/descramble mode for the
port.
None indicates no scrambling.
Payload indicates scrambling of the payload
only.
Frame indicates scrambling of the stream only.
Both indicates scrambling of payload and stream.
• Line Coding Shows the particular DS1/T1 and DS3/T3 coding
convention.
• Cell Mapping Shows the format used to map ATM cells.
Direct indicates direct cell mapping.
Plcp indicates physical layer convergence
protocol mapping.
• Framing Shows the type of framing scheme.
cbit-parity is used for T3 framing.
m23 is used for T3 framing.
Displays the port setting
configurations on an ATM port.
atm show port-settings <port list>| all-ports
ssr(atm-show)# port-settings at.9.1
Port information for Slot 9, Port 1:
Port Type: T3 ATM coaxial cable
Xmt Clock Source: Local
Scramble Mode: Payload
Line Coding: B3ZS
Cell Mapping: Direct
Framing Cbit-Parity
VC Mode: 1 bit of VPI, 11 bits of VCI
Service Definition: ubr-default
Service Class: UBR
Peak Bit Rate: Best Effort
Sustained Bit Rate: 0 Kbits/sec (0 cps)
Maximum Burst Size: 0 cells
Encapsulation Type: Routed LLC
F5-OAM: Requests & Responses
