Network Router User Manual

SmartSwitch Router User Reference Manual 371
Appendix A: New Features Supported on Line Cards
Example 2:
ssr# system show hardware verbose
:
:
Slot CM/1, Module: 10/100-TX Rev. 1.0
Service String: 2_D1.2_0.512_I2.0_2_O2.0_0.512
:
:
The above Service String shows a “non -AA” 10/100 Base TX line card.
Example 3:
ssr# system show hardware verbose
:
:
Slot CM/1, Module: 10/100-TX Rev. 1.0
Service String: 2_D1.3_0.512_I3.0_2_O2.1_0.512
:
:
The above Service String shows a “-AA” 10/100 Base TX line card.
“Non -AA” Line Card “-AA” Line Card
D1.2 or less D1.3 or greater
G2.1.1 or less G2.2 or greater
I2.0 or less I3.0 or greater
O2.0 or less O2.1 or greater
