Network Router User Manual

SmartSwitch Router User Reference Manual 359
Appendix A: New Features Supported on Line Cards
In addition, these cards support all pre-3.0 firmware features. All cards, except for the
gigabit Ethernet cards, also support WFQ.
The following table lists the line cards introduced for the SSR 8000/8600 with the 3.0
firmware release and the supported features.
Line Cards Introduced at the 3.1 Firmware Release (T-Series)
Line cards introduced at the 3.1 firmware release support the following features:
• Routing table on line card
• Weighted Random Early Detection
• Port rate limiting
• Aggregate rate limiting
• Jumbo frame support (except for 10/100 line cards)
• All features supported by 3.0 line cards—see “Line Cards Introduced at the 3.0
Firmware Release (-AA Revision)” on page 358
In addition, these cards support all pre-3.0 firmware features and WFQ.
The following table lists the line cards introduced for the SSR 8000/8600 with the 3.1
firmware release and the supported features.
Line Card Part
Number
Pre-3.0
SSR
Firmware
Features WFQ Listed 3.0 Features
SSR-HTX12-08-AA
XX X
SSR-HTX22-08-AA
XX X
SSR-HFX21-08-AA
XX X
SSR-HFX29-08-AA
XX X
SSR-GSX21-02-AA
XX
SSR-GLX29-02-AA
XX
SSR-GLX70-01-AA
XX
SSR-SERC-04-AA
XX X
SSR-SERCE-04-AA
XX X
SSR-HSSI-02-AA
XX X
