SmartSwitch Router User Reference Manual 355

Chapter 25: WAN Configuration Guide

port set hs.3.1 wan-encapsulation frame-relay speed 45000000

frame-relay create vc port hs.3.1.106

frame-relay define service CIRforR1toR6 cir 45000000 bc 450000

frame-relay apply service CIRforR1toR6 ports hs.3.1.106

vlan create BridgeforR1toR6 port-based id 106

interface create ip FRforR1toR6 address-netmask 100.100.100.6/16 vlan

BridgeforR1toR6

interface create ip lan1 address-netmask 60.60.60.6/16 port et.15.1

vlan add ports hs.3.1.106 to BridgeforR1toR6

vlan add ports et.15.2 to BridgeforR1toR6

qos set ip VideoFromNT high 100.100.100.100 200.200.200.200 any any

qos set ip VideoFrom95 high 200.200.200.200 100.100.100.100 any any

rip add interface all

rip set interface all version 2

rip set auto-summary enable

rip start

system set name R6

arp add 60.60.60.16 mac-addr 000606:060600 exit-port et.15.1
