Chapter 25: WAN Configuration Guide
354 SmartSwitch Router User Reference Manual
Router R5 Configuration File
The following configuration file applies to Router R5.
Router R6 Configuration File
The following configuration file applies to Router R6.
port set et.1.* duplex full
frame-relay create vc port se.6.1.304
vlan create s1 id 200
vlan add ports se.6.1.304,se.6.3 to s1
interface create ip s1 address-netmask 100.100.100.4/16 vlan s1
rip add interface all
rip set interface all version 2
rip set interface all xmt-actual enable
rip set broadcast-state always
rip set auto-summary enable
rip start
system set name R4
----------------------------------------------------------------------
Configuration for ROUTER R5
----------------------------------------------------------------------
port set se.4.1 wan-encapsulation ppp speed 1500000
port set et.1.* duplex full
vlan create s1 id 200
interface create ip lan1 address-netmask 50.50.50.5/16 port et.1.1
vlan add ports se.4.1 to s1
interface create ip s1 address-netmask 100.100.100.5/16 vlan s1
rip add interface all
rip set auto-summary enable
rip set interface all version 2
rip start
system set name R5
arp add 50.50.50.15 mac-addr 000505:050500 exit-port et.1.1
----------------------------------------------------------------------
Configuration for ROUTER R6
----------------------------------------------------------------------
port set et.15.* duplex full
