Chapter 1: Introduction
12 SmartSwitch Router User Reference Manual
For example, the port name et.2.8 refers to the port on the Ethernet line card located in slot
2, connector 8, while the port name gi.3.2 refers to the port on the Gigabit Ethernet line
card located in slot 3, connector 2.
There are a few shortcut notations you can use to reference a range of port numbers. For
example:
• et.(1-3).(1-8) references all the following ports: et.1.1 through et.1.8, et.2.1 through
et.2.8, and et.3.1 through et.3.8.
• et.(1,3).(1-8) references the following ports: et.1.1 through et.1.8, and et.3.1 through
et.3.8
• et.(1-3).(1,8) references the following ports: et.1.1, et.1.8, et.2.1, et.2.8, et.3.1, et.3.8
1000 Base LLX
1
Quad Serial WAN
1,2 3,4
HSSI WAN
1 2
SONET (OC-3c)
1 2 3 4
SONET (OC-12c)
1 2
ATM (OC-3)
1 2
16-slot 100 Base TX
5 6 7 8 13 14 15 16
1 2 3 4 9 10 11 12
Table 3. Port Numbers for Line Cards
Line Card
Port Number Arrangement
(Left to Right)
