Chapter 23: RMON Configuration Guide

324 SmartSwitch Router User Reference Manual

The following shows Host table output without a CLI filter:

The following shows the same rmon show hosts command with a filter applied so that

only hosts with inpkts greater than 500 are displayed:

RMON CLI filters can only be used with the following groups:

•Hosts

•Matrix

• Protocol Distribution

• Application Layer Host

• Network Layer Host

• Application Layer Matrix

• Network Layer Matrix

ssr# rmon show hosts et.5.4

RMON I Host Table

Index: 503, Port: et.5.4, Owner: monitor

Address InPkts InOctets OutPkts OutOctets Bcst Mcst

------- ------ -------- ------- --------- ---- ----

00001D:921086 0 0 102 7140 0 0

00001D:9D8138 1128 75196 885 114387 0 0

00001D:A9815F 0 0 102 7140 0 0

00105A:08B98D 0 0 971 199960 0 0

004005:40A0CD 0 0 51 3264 0 0

006083:D65800 0 0 2190 678372 0 0

0080C8:E0F8F3 0 0 396 89818 0 0

00E063:FDD700 0 0 104 19382 0 0

01000C:CCCCCC 2188 678210 0 0 0 0

01005E:000009 204 14280 0 0 0 0

0180C2:000000 1519 97216 0 0 0 0

030000:000001 168 30927 0 0 0 0

080020:835CAA 885 114387 1128 75196 0 0

980717:280200 0 0 1519 97216 0 0

AB0000:020000 2 162 0 0 0 0

FFFFFF:FFFFFF 1354 281497 0 0 0 0

ssr# rmon apply cli-filter 4

ssr# rmon show hosts et.5.4

RMON I Host Table

Filter: inpkts > 500

Address Port InPkts InOctets OutPkts OutOctets Bcst Mcst

------- ---- ------ -------- ------- --------- ---- ----

00001D:9D8138 et.5.4 1204 80110 941 121129 0 0

01000C:CCCCCC et.5.4 2389 740514 0 0 0 0

0180C2:000000 et.5.4 1540 98560 0 0 0 0

080020:835CAA et.5.4 940 121061 1204 80110 0 0

FFFFFF:FFFFFF et.5.4 1372 285105 0 0
