Chapter 23: RMON Configuration Guide
1
To display Ethernet statistics and related statistics for WAN ports, RMON has to be
activated on that port. To activate RMON on a port, use the frame-relay define service or
ppp define service command, and the frame-relay apply service or ppp apply service
command. For additional information, refer to “Setting up a Frame Relay Service Profile”
on page 342 (for frame relay) and “Setting up a PPP Service Profile” on page 346 (for PPP).
RMON CLI Filters
Because a large number of statistics can be collected for certain RMON groups, you can
define and use CLI filters to limit the amount of information displayed with the rmon
show commands. An RMON CLI filter can only be applied to a current Telnet or Console
session.
To display the RMON 2
Address Map table.
rmon show address-map <port-list>|all-ports
To show Network Layer Host
logs.
rmon show nl-host<port-list>|all-ports [summary]
To show Application Layer
Host logs.
rmon show al-host<port-list>|all-ports [summary]
To show Network Layer
Matrix logs.
rmon show nl-matrix<port-list>|all-ports [order-by
srcdst|dstsrc] [summary]
To show Application Layer
Matrix logs.
rmon show al-matrix<port-list>|all-ports [order-by
srcdst|dstsrc] [summary]
To show all Network Layer
Matrix Top N.
rmon show nl-matrix-top-n
To show all Application
Layer Matrix Top N.
rmon show al-matrix-top-n
To show all user history logs. rmon show user-history
To show probe configuration. rmon show probe-config [basic] [net-config] [trap-
dest]
