Network Router User Manual

Chapter 21: QoS Configuration Guide
306 SmartSwitch Router User Reference Manual
To define an aggregate rate limit policy and apply the policy to an interface, enter the
following commands in Configure mode:
Note:
You cannot use non-IP ACLs for aggregate rate limit policies.
Example Configurations
This section includes examples of rate limiting policy configurations.
Per-Flow Rate Limiting
The following is an example of configuring per-flow rate limiting on the SSR.
Define an aggregate rate limit
policy.
rate-limit <name> aggregate acl <acl list>
rate <rate-limit> { drop-packets|no-
action|lower-priority|lower-priority-
except-control|tos-precedence-rewrite
<val1> |tos-precedence-rewrite-lower-
priority
<val2> } [allocate-resources
during-apply|during-traffic]
Apply an aggregate rate limit
policy to an interface.
rate-limit <name> apply interface
<interface>|all
ipclient1
ipclient2
Backbone
et.1.1
et.1.2
3.3.3.3/8
1.1.1.1/8
et.1.8
2.2.2.2/8
Router
