Chapter 20: Security Configuration Guide
Monitoring Layer-2 Security Filters
The SSR provides display of Layer-2 security filter configurations contained in the routing
table.
To display security filter information, enter the following commands in Enable mode.
Layer-2 Filter Examples
Figure 24. Source Filter Example
Example 1: Address Filters
Source filter: The consultant is not allowed to access any file servers. The consultant is
only allowed to interact with the engineers on the same Ethernet segment – port et.1.1.
All traffic coming from the consultant’s MAC address will be dropped.
Show address filters.
filters show address-filter
[all-source|all-destination|all-flow]
[source-mac
<MACaddr> dest-mac <MACaddr>]
[ports
<port-list>] [vlan <VLAN-num>]
Show port address lock
filters.
filters show port-address-lock ports
[ports
<port-list>] [vlan <VLAN-num>]
[source-mac
<MACaddr>]
Show secure port filters.
filters show secure-port
Show static entry filters. filters show static-entry
[all-source|all-destination|all-flow]
ports
<port-list> vlan <VLAN-num>
[source-mac
<MACaddr> dest-mac <MACaddr>]
et.1.1 et.1.2 et.1.3
Hub
Engineers,
Consultant
Engineering
File Servers
Finance
File Servers
SSR
filters add address-filter name consultant source-mac 001122:334455
vlan 1 in-port-list et.1.1
