SmartSwitch Router User Reference Manual 279
Chapter 20: Security Configuration Guide
Monitoring TACACS Plus
You can monitor TACACS Plus configuration and statistics within the SSR.
To monitor TACACS Plus, enter the following commands in Enable mode:
Configuring Passwords
The SSR provides password authentication for accessing the User and Enable modes. If
TACACS is not enabled on the SSR, only local password authentication is performed.
To configure SSR passwords, enter the following commands in Configure mode:
Layer-2 Security Filters
Layer-2 security filters on the SSR allow you to configure ports to filter specific MAC
addresses. When defining a Layer-2 security filter, you specify to which ports you want
the filter to apply. You can specify the following security filters:
• Address filters
These filters block traffic based on the frame's source MAC address, destination MAC
address, or both source and destination MAC addresses in flow bridging mode.
Address filters are always configured and applied to the input port.
• Port-to-address lock filters
These filters prohibit a user connected to a locked port or set of ports from using
another port.
• Static entry filters
These filters allow or force traffic to go to a set of destination ports based on a frame's
source MAC address, destination MAC address, or both source and destination MAC
addresses in flow bridging mode. Static entries are always configured and applied at
the input port.
• Secure port filters
Show TACACS Plus server
statistics.
tacacs-plus show stats
Show all TACACS Plus
parameters.
tacacs-plus show all
Set User mode password.
system set password login <string>
Set Enable mode password.
system set password enable <string>
