Chapter 18: IPX Routing Configuration Guide

252 SmartSwitch Router User Reference Manual

Configuring IPX Interfaces and Parameters

This section provides an overview of configuring various IPX parameters and setting up

IPX interfaces.

Configuring IPX Addresses to Ports

You can configure one IPX interface directly to a physical port.

To configure an IPX interface to a port, enter the following command in Configure mode:

Configuring Secondary Addresses on an IPX Interface

You can configure secondary addresses on an IPX interface.

To configure a secondary address on an IPX interface, enter the following command in

Configure mode:

Note:

Configuring a secondary address on an IPX interface requires updated SSR

hardware. Please refer to Appendix A for details.

Configuring IPX Interfaces for a VLAN

You can configure one IPX interface per VLAN.

To configure a VLAN with an IPX interface, enter the following command in Configure

mode:

Configure an IPX interface to a

physical port.

interface create ipx

<InterfaceName> address-

mask

<ipxAddr-mask>

port

<port>

Add a secondary address and

encapsulation type to an

existing IPX interface.

interface add ipx <Interface Name> address

<IPX-network-address> output-mac-

encapsulation

<encapsulation-type>

Create an IPX interface for a

VLAN.

interface create ipx

address-mask

<ipxAddr-mask>

vlan

<name>
