Chapter 16: Network Address Translation Configuration Guide

230 SmartSwitch Router User Reference Manual

Then, define the NAT dynamic rules by first creating the source ACL pool and then

configuring the dynamic bindings:

Using Dynamic NAT with Matching Interface Redundancy

If you have redundant connections to the remote network via two different interfaces, you

can use NAT for translating the local address to the different global pool specified for the

two connections. This case is possible when you have two ISPs connected on two different

interfaces to the Internet. Through a routing protocol, some routes will result in traffic

going out of one interface and for others going out on the other interface. NAT will check

which interface the packet is going out from before selecting a global pool. Hence, you can

specify two different global pools with the same local ACL pool on two different

interfaces.

acl lcl permit ip 10.1.1.0/24

nat create dynamic local-acl-pool lcl global-pool 192.50.20.0/24 matching-

if 192-net

nat create dynamic local-acl-pool lcl global-pool 210.50.20.0/24 matching-

if 201-net
