Chapter 15: IP Policy-Based Forwarding Configuration Guide
216 SmartSwitch Router User Reference Manual
For example, to display information about an active IP policy called “p1”, enter the
following command in Enable mode:
Legend:
1. The name of the IP policy.
2. The interface where the IP policy was applied.
3. The load distribution setting for IP-policy statements that have more than one next-
hop gateway; either first available (the default) or round-robin.
4. The names of the profiles (created with an acl statement) associated with this IP
policy.
5. The source address and filtering mask of this flow.
6. The destination address and filtering mask of this flow.
7. For TCP or UDP, the number of the source TCP or UDP port.
8. For TCP or UDP, the number of the destination TCP or UDP port.
9. The TOS value in the packet.
10. IP protocol (ICMP, TCP UDP).
ssr# ip-policy show policy-name p1
--------------------------------------------------------------------------------
IP Policy name : p1
Applied Interfaces : int1
Load Policy : first available
ACL Source IP/Mask Dest. IP/Mask SrcPort DstPort TOS Prot
--- -------------- ------------- --------- --------- --- ----
prof1 9.1.1.5/32 15.1.1.2 any any 0 IP
prof2 2.2.2.2/32 anywhere any any 0 IP
everything anywhere anywhere any any 0 IP
N ext Hop Information
- -------------------
Seq Rule ACL Cnt Action Next Hop Cnt Last
--- ---- -------- --- ----------- -------- --- ----
10 permit prof1 0 Policy Only 11.1.1.2 0 Dwn
20 permit prof2 0 Policy Last 1.1.1.1 0 Dwn
2.2.2.2 0 Dwn
3.3.3.3 0 Dwn
999 permit everything 0 Policy Only drop N/A N/A
65536 deny deny 0 N/A normal fwd N/A N/A
1
2
3
4 5 6 7 8 9 10
11 12 13 14 15 16 17 18
19
