Chapter 13: Routing Policy Configuration Guide

182 SmartSwitch Router User Reference Manual

The following configuration commands for router R1:

• Determine the IP address for each interface.

• Specify the static routes configured on the router.

• Determine its RIP configuration.

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! Create the various IP interfaces.

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

interface create ip to-r2 address-netmask 120.190.1.1/16 port et.1.2

interface create ip to-r3 address-netmask 130.1.1.1/16 port et.1.3

interface create ip to-r41 address-netmask 140.1.1.1/24 port et.1.4

interface create ip to-r42 address-netmask 140.1.2.1/24 port et.1.5

interface create ip to-r6 address-netmask 160.1.1.1/16 port et.1.6

interface create ip to-r7 address-netmask 170.1.1.1/16 port et.1.7

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! Configure a default route through 170.1.1.7

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

ip add route default gateway 170.1.1.7

!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! Configure default routes to the 135.3.0.0 subnets reachable through

! R3.

!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

ip add route 135.3.1.0/24 gateway 130.1.1.3

ip add route 135.3.2.0/24 gateway 130.1.1.3

ip add route 135.3.3.0/24 gateway 130.1.1.3

!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! Configure default routes to the other subnets reachable through R2.

!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

ip add route 202.1.0.0/16 gateway 120.190.1.2

ip add route 160.1.5.0/24 gateway 120.190.1.2

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! RIP Box Level Configuration

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

rip start

rip set default-metric 2

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! RIP Interface Configuration. Create a RIP interfaces, and set

! their type to (version II, multicast).

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

rip add interface to-r41

rip add interface to-r42

rip add interface to-r6

rip set interface to-r41 version 2 type multicast

rip set interface to-r42 version 2 type multicast

rip set interface to-r6 version 2 type multicast
