Chapter 13: Routing Policy Configuration Guide
180 SmartSwitch Router User Reference Manual
The <filter-id> is the identifier of the route-filter associated with this aggregate. If there is
more than one route-filter for any aggregate-destination and aggregate-source
combination, then the ip-router policy aggr-gen destination <aggr-dest-id> source <aggr-
src-id> command should be repeated for each <filter-id>.
Creating an Aggregate Destination
To create an aggregate destination, enter the following command in Configure mode:
Creating an Aggregate Source
To create an aggregate source, enter the following command in Configure mode:
Examples of Import Policies
Example 1: Importing from RIP
The importation of RIP routes may be controlled by any of protocol, source interface, or
source gateway. If more than one is specified, they are processed from most general
(protocol) to most specific (gateway).
RIP does not support the use of preference to choose between routes of the same protocol.
That is left to the protocol metrics.
For all examples in this section, refer to the configuration shown in Figure 18 on page 181.
Create an aggregate
destination.
ip-router policy create aggr-gen-dest <name>
network
<ipAddr-mask>
Create an aggregate source. ip-router policy create aggr-gen-source <name>
protocol
<protocol-name>
