SmartSwitch Router User Reference Manual 149

Chapter 12: BGP Configuration Guide

In Figure 13, router SSR13 has the following configuration:

3. In an Export Statement: The optional-attributes-list option of the ip-router policy

create bgp-export-destination command may be used to send the BGP community

attribute. Any communities specified with the optional-attributes-list option are sent

in addition to any received in the route or specified with the group.

ip-router policy create optional-attributes-list color1 community-id 160

autonomous-system 64902

ip-router policy create optional-attributes-list color2 community-id 155

autonomous-system 64902

ip-router policy create bgp-import-source 902color1 optional-attributes-list

color1 autonomous-system 64899 sequence-number 1

ip-router policy create bgp-import-source 902color2 optional-attributes-list

color2 autonomous-system 64899 sequence-number 2

ip-router policy create bgp-import-source 902color3 optional-attributes-list

color1 autonomous-system 64901 sequence-number 3

ip-router policy create bgp-import-source 902color4 optional-attributes-list

color2 autonomous-system 64901 sequence-number 4

ip-router policy import source 902color1 network all preference 160

ip-router policy import source 902color2 network all preference 155

ip-router policy import source 902color3 network all preference 160

ip-router policy import source 902color4 network all preference 155
