Chapter 12: BGP Configuration Guide

142 SmartSwitch Router User Reference Manual

The configuration for router C1 (a Cisco router) is as follows:

The configuration for router C2 (a Cisco router) is as follows:

EBGP Multihop Configuration Example

EBGP Multihop refers to a configuration where external BGP neighbors are not connected

to the same subnet. Such neighbors are logically, but not physically connected. For

example, BGP can be run between external neighbors across non-BGP routers. Some

additional configuration is required to indicate that the external peers are not physically

attached.

router bgp 1

no synchronization

network 16.122.128.0 mask 255.255.255.0

network 17.122.128.0 mask 255.255.255.0

neighbor 16.122.128.1 remote-as 1

neighbor 16.122.128.1 next-hop-self

neighbor 16.122.128.1 soft-reconfiguration inbound

neighbor 16.122.128.2 remote-as 1

neighbor 16.122.128.2 next-hop-self

neighbor 16.122.128.2 soft-reconfiguration inbound

neighbor 16.122.128.9 remote-as 1

neighbor 16.122.128.9 next-hop-self

neighbor 16.122.128.9 soft-reconfiguration inbound

neighbor 18.122.128.4 remote-as 4
