Chapter 11: OSPF Configuration Guide

120 SmartSwitch Router User Reference Manual

OSPF Configuration Examples

For all examples in this section, refer to the configuration shown in Figure 8 on page 124.

The following configuration commands for router R1:

• Determine the IP address for each interface

• Specify the static routes configured on the router

• Determine its OSPF configuration

Shows information about all valid next

hops mostly derived from the SPF

calculation.

ospf show next-hop-list

Show OSPF statistics.

ospf show statistics

Shows information about OSPF Border

Routes.

ospf show summary-asb

Show OSPF timers.

ospf show timers

Show OSPF virtual-links.

ospf show virtual-links

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! Create the various IP interfaces.

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

interface create ip to-r2 address-netmask 120.190.1.1/16 port et.1.2

interface create ip to-r3 address-netmask 130.1.1.1/16 port et.1.3

interface create ip to-r41 address-netmask 140.1.1.1/24 port et.1.4

interface create ip to-r42 address-netmask 140.1.2.1/24 port et.1.5

interface create ip to-r6 address-netmask 140.1.3.1/24 port et.1.6

!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! Configure default routes to the other subnets reachable through R2.

!+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

ip add route 202.1.0.0/16 gateway 120.1.1.2

ip add route 160.1.5.0/24 gateway 120.1.1.2

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! OSPF Box Level Configuration

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

ospf start

ospf create area 140.1.0.0

ospf create area backbone

ospf set ase-defaults cost 4

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

! OSPF Interface Configuration

!++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

ospf add interface 140.1.1.1 to-area 140.1.0.0

ospf add interface 140.1.2.1 to-area 140.1.0.0
