Network Router User Manual

SmartSwitch Router User Reference Manual 109
Chapter 10: RIP Configuration Guide
Configuration Example
Show RIP information on the specified
interface.
rip show interface <Name or IP-addr>
Show RIP interface policy information.
rip show interface-policy
Show detailed information of all RIP
packets.
rip trace packets detail
Show detailed information of all packets
received by the router.
rip trace packets receive
Show detailed information of all packets
sent by the router.
rip trace packets send
Show detailed information of all request
received by the router.
rip trace request receive
Show detailed information of all response
received by the router.
rip trace response receive
Show detailed information of response
packets sent by the router.
rip trace response send
Show detailed information of request
packets sent by the router.
rip trace send request
Show RIP timer information.
rip show timers
! Example configuration
!
! Create interface SSR1-if1 with ip address 1.1.1.1/16 on port et.1.1 on SSR-1
interface create ip SSR1-if1 address-netmask 1.1.1.1/16 port et.1.1
!
! Configure rip on SSR-1
rip add interface SSR1-if1
rip set interface SSR1-if1 version 2
rip start
!
!
! Set authentication method to md5
rip set interface SSR1-if1 authentication-method md5
!
! Change default metric-in
rip set interface SSR1-if1 metric-in 2
Interface 1.1.1.1 Interface 3.2.1.1
SSR 1
SSR 2
