SmartSwitch Router User Reference Manual 99
Chapter 9: VRRP Configuration Guide
Note:
Since 100 is the default priority, line 9, which sets the priority to 100, is actually
unnecessary. It is included for illustration purposes only.
Configuration of Router R3
The following is the configuration file for Router R3 in Figure 7.
Lines 8 and 9 set the backup priority for Router R3 at 100 for virtual routers
VRID=1 and
VRID=2. Since Router R1 has a priority of 200 for backing up virtual router VRID=2, and
Router R2 has a priority of 200 for backing up virtual router
VRID=1, Router R3 is the
secondary Backup for both virtual routers
VRID=1 and VRID=2.
The following table shows the priorities for each virtual router configured on Router R3.
Note:
Since 100 is the default priority, lines 8 and 9, which set the priority to 100, are
actually unnecessary. They are included for illustration purposes only.
Additional Configuration
This section covers settings you can modify in a VRRP configuration, including backup
priority, advertisement interval, pre-empt mode, and authentication key.
1: interface create ip test address-netmask 10.0.0.3/16 port et.1.1
!
2: ip-redundancy create vrrp 1 interface test
3: ip-redundancy create vrrp 2 interface test
4: ip-redundancy create vrrp 3 interface test
!
5: ip-redundancy associate vrrp 1 interface test address 10.0.0.1/16
6: ip-redundancy associate vrrp 2 interface test address 10.0.0.2/16
7: ip-redundancy associate vrrp 3 interface test address 10.0.0.3/16
!
8: ip-redundancy set vrrp 1 interface test priority 100
9: ip-redundancy set vrrp 2 interface test priority 100
!
10: ip-redundancy start vrrp 1 interface test
11: ip-redundancy start vrrp 2 interface test
12: ip-redundancy start vrrp 3 interface test
Virtual Router Default Priority Configured Priority
VRID=1 – IP address=10.0.0.1/16 100 100 (see line 8)
VRID=2 – IP address=10.0.0.2/16 100 100 (see line 9)
VRID=3 – IP address=10.0.0.3/16 255 (address owner) 255 (address owner)
