SmartSwitch Router User Reference Manual 89

Chapter 8: IP Routing Configuration Guide

To display router discovery information:

Legend:

1. Information about the RDISC task.

2. Shows when the last router advertisement was sent and when the next advertisement

will be sent.

3. The interface on which router advertisement is enabled.

4. Multicast address.

5. Current values for the intervals between the sending of router advertisements and the

lifetime of addresses sent in a router advertisement.

6. IP address that is included in router advertisement. The preference of this address as a

default route is 0, the default value.

7. Shows configured values for the specified interface.

ssr# rdisc show all

Task State: <Foreground NoResolv NoDetach>

Send buffer size 2048 at 812C68F8

Recv buffer size 2048 at 812C60D0

Timers:

RouterDiscoveryServer Priority 30

RouterDiscoveryServer_SSR2_SSR3_IP <OneShot>

last: 10:17:21 next: 10:25:05

Task RouterDiscoveryServer:

Interfaces:

Interface SSR2_SSR3_IP:

Group 224.0.0.1:

minadvint 7:30 maxadvint 10:00 lifetime 30:00

Address 10.10.5.254: Preference: 0

Interface policy:

Interface SSR2_SSR3_IP* MaxAdvInt 10:00
