ELECTRICAL SPECIFICATIONS PER DIODE (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Cathode to anode breakdown voltage V
BR
I
R
= 100 μA 600 - -
V
Forward voltage V
FM
I
F
= 100 A - 1.28 1.44
I
F
= 100 A, T
J
= 125 °C - 1.13 1.24
I
F
= 200 A - 1.48 1.66
I
F
= 200 A, T
J
= 125 °C - 1.37 1.55
Reverse leakage current I
RM
V
R
= V
R
rated - 0.1 50 μA
T
J
= 175 °C, V
R
= V
R
rated - 0.25 2 mA
Junction capacitance C
T
V
R
= 600 V - 72 - pF
DYNAMIC RECOVERY CHARACTERISTICS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Reverse recovery time t
rr
I
F
= 1.0 A, dI
F
/dt = 200 A/μs, V
R
= 30 V - 44 -
nsT
J
= 25 °C
I
F
= 50 A
dI
F
/dt = 200 A/μs
V
R
= 200 V
- 104 -
T
J
= 125 °C - 210 -
Peak recovery current I
RRM
T
J
= 25 °C - 10 -
A
T
J
= 125 °C - 22 -
Reverse recovery charge Q
rr
T
J
= 25 °C - 520 -
nC
T
J
= 125 °C - 2200 -
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Junction to case, single leg conducting
R
thJC
- - 0.43
°C/WJunction to case, both leg conducting - - 0.215
Case to heatsink R
thCS
Flat, greased surface - 0.05 -
Weight -30- g
Mounting torque -1.3-Nm
Case style SOT-227
