ELECTRICAL SPECIFICATIONS PER DIODE (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Cathode to anode breakdown voltage V
BR
I
R
= 100 μA 400 - -
V
Forward voltage V
FM
I
F
= 100 A - 1.06 1.24
I
F
= 100 A, T
J
= 175 °C - 0.85 0.95
Reverse leakage current I
RM
V
R
= V
R
rated - 1.3 50 μA
T
J
= 175 °C, V
R
= V
R
rated - 0.36 4 mA
Junction capacitance C
T
V
R
= 400 V - 100 - pF
DYNAMIC RECOVERY CHARACTERISTICS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Reverse recovery time t
rr
I
F
= 1.0 A, dI
F
/dt = 200 A/μs, V
R
= 30 V - 40 -
nsT
J
= 25 °C
I
F
= 150 A
dI
F
/dt = 200 A/μs
V
R
= 200 V
-93-
T
J
= 125 °C - 172 -
Peak recovery current I
RRM
T
J
= 25 °C - 10.5 -
A
T
J
= 125 °C - 20.2 -
Reverse recovery charge Q
rr
T
J
= 25 °C - 490 -
nC
T
J
= 125 °C - 1740 -
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS MIN. TYP. MAX. UNITS
Junction to case, single leg conducting
R
thJC
- - 0.43
°C/WJunction to case, both leg conducting - - 0.215
Case to heatsink R
thCS
Flat, greased surface - 0.05 -
Weight -30- g
Mounting torque -1.3-Nm
Case style SOT-227
