VS-HFA140FA120
www.vishay.com
Vishay Semiconductors
Revision: 20-Jul-12
6
Document Number: 94746
For technical questions within your region: [e-mail]
, [e-mail], [e-mail]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
ORDERING INFORMATION TABLE
CIRCUIT CONFIGURATION
CIRCUIT
CIRCUIT
CONFIGURATION CODE
CIRCUIT DRAWING
2 separate diodes,
parallel pin-out
F
LINKS TO RELATED DOCUMENTS
Dimensions www.vishay.com/doc?95423
Part marking information www.vishay.com/doc?95425
1
2
3
4
5
6
7
Device code
5
1
32 4 6 7
HFVS- A 140 F A 120
- HEXFRED
®
family
- Vishay Semiconductors product
- Process designator (A = Electron irradiated)
- Average current (140 = 140 A)
- Circuit configuration (2 separate diodes, parallel pin-out)
- Package indicator (SOT-227 standard isolated base)
- Voltage rating (120 = 1200 V)
1
43
2
Lead Assignment
1
4
2
3
