T9S0__2803
Phase Control Thyristor
Powerex, Inc., 173 Pavilion Ln, Youngwood, Pennsylvania 15697-1800 [phone] www.pwrx.com 2850 Amperes 800 Volts
0
500
1000
1500
2000
2500
3000
3500
4000
4500
0 500 1000 1500 2000 2500 3000 3500
Pavg (Watts)
Iavg (A)
Maximum On-State Power Dissipation
Sinusoidal Waveform
60°
90°
120°
180°
0° 180° 360°
CONDUCTION ANGLE
50
70
90
110
130
150
0 500 1000 1500 2000 2500 3000 3500
Tc (°C)
Iavg (A)
Maximum Allowable Case Temperature
Sinusoidal Waveform
60°
90°
120°
180°
0° 180° 360°
CONDUCTION ANGLE
