Instruction Manual

4
PS21267-P / PS21267-AP
Intellimod™ Module
Dual-In-Line Intelligent Power Module
30 Amperes/600 Volts
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 [phone] www.pwrx.com
08/10 Rev. 01
Electrical and Mechanical Characteristics, T
j
= 25°C unless otherwise specied
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Control Sector
Circuit Current I
D
V
D
= V
DB
= 15V, V
IN
= 5V, — — 7.00 mA
Total of V
P1
-V
PC
, V
N1
-V
NC
V
D
= V
DB
= 15V, V
IN
= 0V, — — 7.00 mA
Total of V
P1
-V
PC
, V
N1
-V
NC
V
D
= V
DB
= 15V, V
IN
= 5V, — — 0.55 mA
V
UFB
-V
UFS
, V
VFB
-V
VFS
, V
WFB
-V
WFS
V
D
= V
DB
= 15V, V
IN
= 0V, — — 0.55 mA
V
UFB
-V
UFS
, V
VFB
-V
VFS
, V
WFB
-V
WFS
Fault Output Voltage V
FOH
V
SC
= 0V, F
O
Circuit: 10kΩ to 5V Pull-up 4.9 — — Volts
V
FOL
V
SC
= 1V, I
FO
= 1mA — — 0.95 Volts
Input Current I
IN
V
IN
= 5V 1.0 1.5 2.00 mA
Short-Circuit Trip Level* V
SC(ref)
T
C
= 20 ~ 100°C, V
D
= 15V 0.45 — 0.52 Volts
Supply Circuit Undervoltage UV
DBt
Trip Level, T
j
≤ 125°C 10.0 — 12.0 Volts
Protection UV
DBr
Reset Level, T
j
≤ 125°C 10.5 — 12.5 Volts
UV
Dt
Trip Level, T
j
≤ 125°C 10.3 — 12.5 Volts
UV
Dr
Reset Level, T
j
≤ 125°C 10.8 — 13.0 Volts
Fault Output Pulse Width** t
FO
C
FO
= 22nF 1.0 1.8 — ms
ON Threshold Voltage V
th(on)
Applied between U
P
, V
P
, W
P
-V
PC,
2.1 2.3 2.6 Volts
OFF Threshold Voltage V
th(off)
U
N
, V
N
, W
N
-V
NC
0.8 1.4 2.1 Volts
Thermal Characteristics
Characteristic Symbol Condition Min. Typ. Max. Units
Junction to Fin R
th(j-f)Q
IGBT Part (Per 1/6 Module) — — 1.80 °C/W
Thermal Resistance R
th(j-f)D
FWDi Part (Per 1/6 Module) — — 3.00 °C/W
Contact Thermal Resistancw R
th(c-f)
Case to Fin (Per 1 Module) — — 0.067 °C/W
* Short-Circuit protection is functioning only at the lower arms. Please select the value of the external shunt resistor such that the SC trip level is less than 30A.
**Fault signal is asserted when the lower arm short circuit or control supply under-voltage protective functions operate. The fault output pulse-width t
FO
depends on the capacitance value
of C
FO
according to the following approximate equation: C
FO
= (12.2 x 10
-6
) x t
FO
{F} .
