GB50YF120N
IGBT Fourpack Module, 50 A
Vishay High Power Products
Fig. 1 - Maximum DC Collector Current vs.
Case Temperature
Fig. 2 - Power Dissipation vs. Case Temperature
Fig. 3 - Forward SOA
T
C
= 25 °C; T
J
≤ 150 °C
Fig. 4 - Reverse Bias SOA
T
J
= 150 °C; V
GE
= 15 V
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL MIN. TYP. MAX. UNITS
Junction to case IGBT R
thJC
(IGBT) - - 0.38
°C/WJunction to case DIODE R
thJC
(DIODE) - - 1.00
Case to sink, flat, greased surface R
thCS
(MODULE) - 0.05 -
Mounting torque (M5) 2.7 - 3.3 Nm
Weight - 170 - g
