MITSUBISHI HVIGBT MODULES
CM400DY-66H
HIGH POWER SWITCHING USE
INSULATED TYPE
● IC...................................................................400A
● V
CES ....................................................... 3300V
● Insulated Type
● 2-elements in a pack
APPLICATION
Inverters, Converters, DC choppers, Induction heating, DC to DC converters.
CM400DY-66H
HVIGBT MODULES (High Voltage Insulated Gate Bipolar Transistor Modules)
OUTLINE DRAWING & CIRCUIT DIAGRAM Dimensions in mm
HVIGBT (High Voltage Insulated Gate Bipolar Transistor) Modules
C2
G2
C2
E2
E2
CIRCUIT DIAGRAM
G1
E1
E1
C1
G1
114
57 ±0.25 57 ±0.25
130
E1
C2E1
E2C1
C2
E2(C1)
CM
24.5
40
20
124
±0.25
140
7.2
48.8 53.6
36.3
4 - M8 NUTS
6 - φ 7 MOUNTING HOLES
5 - M4 NUTS
G2
18
61.5
5
38
15
39.55.7
15
30
28
LABEL
