70HF(R) Series Vishay High Power Products Standard Recovery Diodes (Stud Version), 70 A FEATURES • • • • • High surge current capability Designed for a wide range of applications Stud cathode and stud anode version Leaded version available Types up to 1600 V VRRM RoHS COMPLIANT • RoHS compliant • Designed and qualified for industrial level TYPICAL APPLICATIONS DO-203AB (DO-5) • • • • PRODUCT SUMMARY IF(AV) 70 A Converters Power supplies Machine tool controls Battery charges MAJOR RATINGS AND CHARA
70HF(R) Series Vishay High Power Products Standard Recovery Diodes (Stud Version), 70 A FORWARD CONDUCTION PARAMETER SYMBOL Maximum average forward current at case temperature Maximum RMS forward current IF(AV) TEST CONDITIONS 180° conduction, half sine wave IFSM t = 8.3 ms t = 10 ms t = 10 ms I2 t t = 8.3 ms t = 10 ms t = 8.
70HF(R) Series Standard Recovery Diodes (Stud Version), 70 A Vishay High Power Products ΔRthJC CONDUCTION CONDUCTION ANGLE SINUSOIDAL CONDUCTION RECTANGULAR CONDUCTION 180° 0.08 0.06 120° 0.10 0.11 90° 0.13 0.14 60° 0.19 0.20 30° 0.30 0.30 TEST CONDITIONS UNITS TJ = TJ maximum K/W 180 70HF(R) Series (100V to 1200V) R thJC (DC) = 0.
70HF(R) Series Vishay High Power Products Standard Recovery Diodes 90 A S R th K/W .3 =0 K/ W K/W 0.5 W K/ 60 1. 5 W K/ 70 0.
70HF(R) Series Vishay High Power Products 120 = 3 0. K/ W SA K/ W W K/ a elt -D 80 0. 7 1 W K/ 100 R th DC 180° 120° 90° 60° 30° 5 0. 1.
0HF(R) Series Vishay High Power Products Standard Recovery Diodes (Stud Version), 70 A Fig.
Outline Dimensions Vishay High Power Products DO-203AB (DO-5) for 70HF(R) and 71HF(R) Series DIMENSIONS FOR 70HF(R) SERIES in millimeters (inches) Ø 14.6 (0.57) 6.1/7 (0.24/0.27) 4 (0.16) 4 (0.16) MIN. 25.4 (1) MAX. 10.8 (0.42) 11.4 (0.45) 11.1 ± 0.4 (0.44 ± 0.02) 1/4" 28UNF-2A for metric devices: M6 x 1 1.20 (0.04) Document Number: 95343 Revision: 29-Sep-08 17.40 (0.68) For technical questions concerning discrete products, contact: diodes-tech@vishay.
Outline Dimensions Vishay High Power Products DO-203AB (DO-5) for 70HF(R) and 71HF(R) Series DIMENSIONS FOR 71HF(R) SERIES in millimeters (inches) 12.2 (0.48) MAX. Ø 7 (0.28) MAX. 134.4 (5.29) MAX. www.vishay.com 2 123 (4.84) MAX. For technical questions concerning discrete products, contact: diodes-tech@vishay.com For technical questions concerning module products, contact: ind-modules@vishay.
