User guide

20ETS12PbF SAFEIR Series
Bulletin I2192 12/04
Fig. 8 - Thermal Impedance Z
thJC
Characteristics
Fig. 7 - Forward Voltage Drop Characteristics
1
10
100
1000
00.511.522.533.54
T = 25°C
J
Instantaneous Forward Current (A)
Instantaneous Forward Voltage (V)
T = 150°C
J
20ETS.. Series
0.01
0.1
1
10
0.0001 0.001 0.01 0.1 1
Square Wave Pulse Duration (s)
thJC
Steady State Value
(DC Operation)
Sing le Pulse
D = 0.50
D = 0.33
D = 0.25
D = 0.17
D = 0.08
20ETS.. Series
Transient Thermal Impedance Z (°C/W)
Document Number: 94341
www.vishay.com
4
