Major Ratings and Characteristics
I
F(AV)
Sinusoidal
waveform
V
RRM
1200 V
I
FSM
300 A
V
F
@ 10 A, T
J
= 25°C 1.0 V
T
J
- 40 to 150 °C
Characteristics Values Units
20 A
Output Current in Typical Applications
Description/ Features
The 20ETS12PbF rectifier SAFEIR series has
been optimized for very low forward voltage drop,
with moderate leakage. The glass passivation
technology used has reliable operation up to 150°C
junction temperature.
Typical applications are in input rectification and
these products are designed to be used with
International Rectifier Switches and Output
Rectifiers which are available in identical package
outlines.
Capacitive input filter TA = 55°C, TJ = 125°C,
16.3 21
A
common heatsink of 1°C/W
INPUT RECTIFIER DIODE
Lead-Free ("PbF" suffix)
V
F
< 1V @ 10A
I
FSM
= 300A
V
RRM
= 1200V
SAFEIR Series
20ETS12PbF
Bulletin I2192 12/04
TO-220AC
Package Outline
