15. Technical Data
Installation ........................................................DIN-RAIL,35mm
Operating voltage ............................................100-240V/AC,50/60Hz
Power input ......................................................Max. 30 mA
Power consumption ..........................................Average:3W
External fuses recommended ...........................2A,250V
Internal battery (time) .......................................Lithiumbattery,cannotbereplaced
Switchingpower(externalfuserequired) .........250V/AC,16A(ohmicload)
 250V/AC,3A(inductiveload)
 24V/DC,16A
Important note:
 OUT1toOUT3:Onlyfunctionalseparation(observenotesintheoperatinginstructions!)
Input IN1 to IN3 ...............................................LogicalLow/Lat0to5V/AC
 LogicalHigh/Hat15V/ACtomax.250V/AC
Note:IN1-3,OUT1-3,mainsunit ......................OvervoltagecategoryIII,300V
 Degreeofcontamination:2
 Voltageresistance:4000Vmax.
Inputs IN4 and IN5 ...........................................LogicalLow/Lat0to1.0V/DC
 LogicalHigh/Hat1.5V/DCtomax.32V/DC
Internal temperature sensor .............................-40°Cto+125°C,accuracy:+/-2°C
RS485-voltage supply ......................................Internal,5V/DC,150mAmax.
RS485 bus driver ..............................................MAX485
RS485 interrupt line ..........................................Opendrain,max.10mA,5Vmax.,frommaster
RS485 operating modes ...................................Master/Slave
RS485 galvanic insulation ................................Yes,present
TransmissionfrequencyGSM/GPRSmodule ..GSM900:880-915MHz
 GSM1800:1710-1785MHz
Transmissionpower..........................................GSM900:33dBm±2dBm
 GSM1800:30dBm±2dBm
RequiredSIMcard ...........................................Mini SIM 3 V
Requiredwireendsleeves ...............................IN1,IN2,IN3,OUT1,OUT2,OUT3:2,5mm²
 IN4,IN5:1,5mm²
Enclosed aerial .................................................MMCX-plug,cablelengthapprox.3m
Ambience conditions ........................................Temperaturerange-10°Cto+55°C;airhumiditymax.90%rel.
humidity,non-condensing
Dimensions .......................................................120x84x52,5mm
Weight ..............................................................205 g
