Instructions

2. Time between Relay Switching (RELAYTIME)

Sincethisproductmostlikelyisusedtoswitchcomplicatedconsumers,activatinganddeactivatingtooquicklymay

causedamage.Therefore,thetimebetweentwoconditionchangesofarelaycanbedened:

SET RELAYTIME <Time> #1513

 Time: 1-30seconds,factorysetting=5seconds

All switching commands during this time window are rejected. Only BLOCK mode has a higher priority.

TESTandRESETrequeststhecurrentcongurationaccordinglyandresetsit.

3. Hysteresis for TEMP (HYSTEMP)

Thefactorysettingswerealreadychosentobesuitableformostapplications.Changesareonlynecessaryinexcep-

tions.

Thehysteresisfunctionwasdeveloped toprevent undesiredalarms.Hysteresiswillcausethe alarmthresholdto

changeafterthehysteresisvalueisexceeded.Thisrequirestheanaloguevaluetoenterthepermittedareafurther

before the alarm condition stops.

Analogue value

Upper threshold

Measured value

Lower threshold

Alarm with hysteresis

Hysteresis

Time

Alarm without hysteresis

Thesehysteresisvaluesaresetindependentlyofthealarmvaluewiththefollowingcommands:

SET HYSTEMP <value> #1513

 Regardsfunction:TEMP

 Thevaluerangeforthecommandis:HYSTEMP0.....99(01=0.1°C);defaultsetting0.2°C

 Thevalue„0“deactivatesthisfunction(atyourownrisk-toofrequentswitchingprocesses!)

TheactionTESTforanyfunctiondisplaysthecurrentstatusofallhysteresisvalues.RESETresetstothebasicset-

tings.
