e) Further Sensors
Theproductalsohasadditionalsensorsthatcanbeusedforalarming.
1. Internal Temperature Measurement (TEMP)
TheproducthasaninternaltemperaturesensorontheGSMPCBthatcanbeusedtoissueanalarmincaseof
temperaturesthatgivereasonforconcern(e.g.lessthan0°Corabove+40°C).However,theintrinsictemperature
ismeasuredhereinsteadoftheambiencetemperature.Thecommandforcongurationis:
SET TEMP <MIN. Temp.> <MAX. Temp.> #1513
 Min.value:-390(-39.0°C)
 Max.value:850(+85,0°C)
 WhenusingMINandMAXvalues,thisthresholdisdeactivatedautomaticallysincethereisnomeasured
value behind it.
 Thevalue„MIN.Temp“mustbelessthanthevalue„MAX.Temp.“.
Example:
SET TEMP -10 +225 #1513
Analarmistriggeredbelow-1°Candabove+22.5°C.
TESTandRESETrequeststhecurrentconrmationaccordinglyandresetsthemtoDEFAULT<off>.
 Thereis anothersystem functionthat inuencesthis command:HYSTEMP. Formore onthis, seethe
corresponding chapter.
2. Top Cover Sensor (TOPCOVER)
Tooffertheuseraccesstotheproductformaintenancewithouthavingtoremoveitfromtheinstallation,theSIMcard
andtheUSBsocketarefreelyaccessibleafterthelidisremoved.Theproducthasalightsensortorecogniseand
alarmunauthorisedaccess.Thiscanbeusedforalarmingoncethecapisremoved.Thecommandforactivationis:
SET TOPCOVER [<SMS>] [<Block>] #1513
WhenusingtheparameterSMS,analarmSMSissentwhenremovingthelidinmode„ALARMENABLE“.When
BLOCKisused,BLOCKmodeisactivatedautomatically.Bothcanbecombined.Ifnoparameterisindicated,the
functionisdeactivated(identicalwithRESET).
TESTandRESETrequeststhecurrentconrmationaccordinglyandresetsthemtoDEFAULT<off>.
