d) Relay Outputs
AllrelayswitchinginputsaresecurelyinsulatedfromareasoftheGSMPCBthatmaybetouched.Theseparation
for safety low-voltage is designed for overvoltage category III and contamination degree 2 according to EN 60664-1.
Underconsiderationoftheconditionsnamed,theindustrialinstallationsmaybeused.
 The relay switching contacts onlyhave a functional insulation against each other. The relay therefore
must only switch either mains voltages only or low safety voltages only. Mixed operation (switching mains
voltage AND switching safety low voltage) is not permissible.
ThestatusoftherelaysisautomaticallysignalledviatheLEDsandindicatedintheSTATUS-SMS.Itshouldalsobe
observed that all relays deactivate at once and cannot be activated anymore when the BLOCK mode is activated.
Observethefollowingwhenconnectingthe230Vswitchinginputs:
• Compliance with the safety notes
• Wire end sleeves must be used
• Linecross-sectionupto2.5mm²
• TheprotectionclassappliesonlyagainsttheinternalGSMPCB,notbetweentherelays.
• Theswitchingpowersareindicatedinthetechnicaldata.
1. Direct Switching (OUT1, OUT2, OUT3)
Allrelayscanbemanuallyswitchedbytextmessageatonceandwithoutdelay.Thisappliesto„ALARMENABLE“as
well,butnotinBLOCKmode.Thecommandis:
SET <OUT1/OUT2/OUT3> #1513 Switching on
RESET <OUT1/OUT2/OUT3> #1513 Switching off
Thisfunctioncanbecombined.Thereforethefollowingcommands:
SET OUT1 #1513, SET OUT2 #1513, SET OUT3 #1513
…andthecommand:
SET OUT1 OUT2 OUT3 #1513
..will have the same result.
