6.6.5.1. CC1
This branch menu displays the controller ID, Hardware Version, Firmware, and Boot
loader Version
Fig. 43: “CC1” (Controller Info 1) Display
1 – Controller ID Number
The iNetVu™ Controller Serial Number is located on the base of the controller. It is the last 4 digits
of the Serial Number.
2 – Signal Quality Threshold
Minimum SNR Value required for the iNetVu
TM
7000 Controller to validate signal.
3 – 7000 Controller Board Hardware Type Version
4 – 7000 Controller Firmware and Boot loader version
The firmware version is to the left of the dash (i.e. 7.0.0.1-7.0.0.1), and the boot loader version is
to the right of the dash (i.e. 7.0.0.1-7.0.0.1).
6.6.5.2. CC2
This branch menu displays the controller MAC address and Configuration ID.
Fig. 44: “CC2” (Controller Info 2) Display
1 – iNetVu
TM
7000 Controller MAC address
2 – iNetVu
TM
7000 Controller Configuration ID (for internal use).
ID: 9999 SQ_T: 31 HW:0
FBV:7.0.0.1—7.0.0.1
1
2
3
4
MA:00-40-05-56-3F-C8
CONF_ID:75
