6.6.4.3. DPLY
1 – Elevation Movement
User-defined elevation angle of deploy
2 – Polarization Movement
User-defined polarization angle of deploy
3 – Azimuth Movement
User-defined azimuth angle of deploy
4 – Deploy
Automatically moves antenna to the manually entered Elevation, Azimuth and Polarization angles.
E: +20 P+60
A +180 DPLY
1
2
3
4
