6.6.3.2. MOD
1 – Configured Satellite Modem Receive Frequency in MHz with no decimals.
2 – Configured Satellite Modem Symbol Rate in Ksps.
3 – Transmit and Receive Polarization.
HH – Horizontal Transmit, Horizontal Receive
HV – Horizontal Transmit, Vertical Receive
VH – Vertical Transmit, Horizontal Receive
VV – Vertical Transmit, Vertical Receive
Transmit polarity is represented by the first character, while Receive polarity is represented by the
second character, hence TR
4 – Hemisphere of location of modem.
This is typically used for the HNS modem; other service providers may not need this requirement.
E – East
W – West
Modems operating in the eastern hemisphere require E to be selected, while modems operating in
the western hemisphere require W to be selected.
0990 30000 TR :HV H :W
1
4
2 3
