subnet IP address, as well as the controller gateway IP address.
IP
Configuration screen of the controller IP address, and the VSAT
modem’s IP address.
SR
Service Configuration screen, allows for the type of service selection and
means of communication.
6.6.3.1. SAT
Allows for the Configuration of the target satellite and the satellite polarization offset.
This menu also allows the enabling of the reference satellite search option as explained
in the “Monitor” section of this manual.
Fig. 27: “SAT” (Satellite) Configuration Display
1 – Target Satellite
Orbital slot / Longitude of the desired Satellite. The Find Satellite command will use this value
when attempting to find and lock onto a satellite signal.
2 – Satellite Transmit Polarization Offset (range: -90 to +90)
In North America and not limited to the rest of the world
1200/1800 – Vertical Transmit (Offset = 0), Horizontal Transmit (Offset = 90)
980/740 – Offset = 0 (considering OMT is adjusted manually)
3 – Reference Satellite Longitude and hemisphere.
D – Disable Reference Satellite Option
E – Enable Reference Satellite Option
4 – Reference Satellite Transmit Polarization Offset (range: -90 to +90)
093.0W O: +90
008.7W :E O :+90
