6.6.1.1. MAIN

This branch menu displays the real-time Elevation, Azimuth, Polarization Angles, their

respective limits (Up, Down, Stow), the RF Receive Signal, Signal Strength, and the

System Status.

Fig. 14: “MAIN” (Main) Display

1 – Elevation Angle and Limit Indicators

Ka66/740/950/980 Mobile Platform Range: -90.0 to 65+

1200/1800 Mobile Platform Range: -90.0 to 75+

1.2m Flyaway Antenna 5.0 to 80

Elevation Angle will be –90.0 when the Elevation Stow Indicator is ON for mobile units

U Elevation Up Limit has been reached.

Typically set above 75 for 1200 Mobile Platforms, and above 65 for 740/950/980 Mobile

Platforms.

D Elevation Down Limit has been reached.

Typically set between 5 and 10 for 1200 Mobile Platforms and between 0 and 10 for

Ka66/740/950/980 Mobile Platforms.

S Elevation Stow Limit has been reached.

2 – Azimuth Angle and Stow Limit Indicator

Range: -200 to +200

Flyaway Range: ±75

S Azimuth Stow Limit has been reached.

Mobile Platform should be physically centered on the Azimuth axis.

3 – Polarization Angle and Stow Limit Indicator

740/950/980 Mobile Platform Range: -70 to 70

1200/1800 Mobile Platform Range: -90 to 90

Ka66 / 1800 Circular Band Signals will have the Polarization Angle disabled, and will display

‘DDDDD”

E-90.0 U D S A -45.7 S ST

P-34.6 S 15U M140D VV
