6.6.1. MONITOR
This section describes briefly what each item and menu represents. For a more detailed
explanation of each menu, see the configuration section of this manual. ( Section 6.6.3)
Fig. 13: Monitor Menu
MAIN
Displays real-time system status and receive signal.
EL
(Elevation) Displays real-time current drawn and speed settings for the
elevation motor, as well as real-time elevation angle and limits, offset,
window size, and Elevation adjustment gap.
AZ
(Azimuth) Displays real-time current drawn and speed settings for the
azimuth motor, as well as real-time azimuth angle and limits, window
size, pot factor, and zero factor.
PL
(Polarization) Displays real-time current drawn and speed settings for
the polarization motor, as well as real-time polarization angle and limits,
window size, pot factor, and zero factor.
GPS
Displays GPS Status and coordinates.
CP
(Compass) Displays compass status, compass elevation angle reading,
and 4-point compass readings.
DVB
(DVB Tuner) Displays the DVB Tuner’s operating frequency, symbol
rate, and code rate. This branch also contains the frequency, symbol
rate, and code rate of a reference transponder.
SAT
(Satellite) Displays Target Satellite longitude and the antennas target
coordinates. This branch also contains longitudinal coordinates of a
reference satellite used for searching.
MOD
(Modem) Displays Modem Parameters.
IP
Displays IP of iNetVu 7000’s Ethernet Port, and the VSAT modem.
GW
(Gateway) Displays Subnet, and Gateway IP.
MAIN EL AZ PL GPS CP
DVB SAT MOD IP GW
