3. After this is complete, go back to the Operations menu by pressing the “Exit”
button to navigate backwards.
4. Advance to “PL_C” using the arrows and select the “Enter” key on the keypad.
IMS will begin the Polarization Calibration Function. Verify that there are no
obstructions that would impede a full Polarization sweep. Confirm the pot and
zero factors when prompted and save.
5. After this is complete, navigate to the “Config” menu from the keypad. The “Exit”
button on the keypad can be used to navigate back to the original menu, and the
“Enter” button will allow the user to enter into a menu.
6. Navigate to “C&P” in the configuration menu and select the “Enter” button on the
keypad.
7. A screen containing RF and Platform Data will appear. Navigate to the far bottom
right section of the screen where the platform description appears (i.e. A12B for
1.2 mobile unit), and click on the ‘↑’ arrow once. This action will allow you to
make modifications to that section.
Fig. 6: C&P Screen from Configuration
8. Next to the dish size (i.e. A12B, etc.), there exists a 4-digit platform serial number
as outlined in the figure above. Change this number to the iNetVu
TM
Platform
Serial Number by using the ‘→’ to advance between digits, and the ‘↑’ or ‘↓’ to
change the value of the digit. The iNetVu™ Mobile Platform Serial Number will
be found on your iNetVu™ Mobile Platform and ONLY THE LAST 4 DIGITS
should be entered.
9. Click the “Enter” button on the keypad once the serial number has been entered,
and exit the configuration menu by click the “Exit” button twice. One time to
return to the configuration screen and one more time to exit the configuration
screen.
10. Once prompted if you would like to save the configuration, press the ‘↑’ button
such that ‘Y’ is selected for “yes”, and press, “Enter”.
That’s it. You have successfully completed the installation and setup of the iNetVu™
7000 Controller and are ready to find satellite.
