4.3. Typical Connection – PC Free
Fig. 5: iNetVu™ 7000 Controller PC Free Connection Configuration
!
90 - 264VAC
GPS
Antenna
MOTOR
CONTROL
SENSOR
CABLE
Satellite Modem / VSAT
RX
Network Cable
RG6 Coaxial Cable
Network Cable
Power Cable
Sensor Cable
Motor Control Cable
RX
TX
