E (Value)
The angle the compass is set to read from
O (Value)
Compass Offset
RF (Mode)
RF Signal Type (Normal, Overridden) and Threshold
S&P
Searching and Peaking Mode (Find Satellite and Peak on DVB, Modem, or RF)
DH (DHCP)
Enables or Disables DHCP in the controller
Beep
Enables or Disables the beeping noise when navigating the LCD Interface
Platform Type
Setting for the platform type and serial number
C&P
MP
Enables or Disables Motion Protection
R_IP (Address)
Router IP Address (still under C-COM development)
RT
D_IP (Address)
DNS IP Address (still under C-COM development)
S_IP (Address)
7000 Controller Subnet IP Address
G&S
G_IP (Address)
7000 Controller Gateway IP Address
C_IP (Address)
Controller IP Address
IP
M_IP (Address)
Modem IP Address
Service
Service In Use (iDirect, Hughes, Etc.)
Interface
Modem Communication Interface (i.e. Telnet, HTTP, Console, etc.)
DEBUG
Debugging Interface (For internal use only)
SR
Password
Modem Password if necessary
TEST
E (Range)
Range and speed of start angle to end angle of elevation movement
P (Range)
Range and speed of start angle to end angle of polarization movement
A (Range)
Range and speed of start angle to end angle of azimuth movement
Axis Selection
Selection for Axis to be tested, and test looping option setting
E&A&P
TST
Initiates the testing on the specified axis and range.
CP
CP
Performs a Check Compass Operation
E (Angle)
The target elevation angle for antenna deployment
P (Angle)
The target polarization angle for antenna deployment
A (Angle)
The target azimuth angle for antenna deployment
DPLY
DPLY
Initiates the deploy command to the specified antenna deployment angles
E (Angle)
The target elevation angle for antenna deployment and compass reading
P (Angle)
The target polarization angle for antenna deployment and compass reading
A (Angle)
The target azimuth angle for antenna deployment and compass reading
DPLY_C
DPLY
DPLY – initiates a compass reading at the specified antenna deployment angles
A_ACP
A_ACP
Initiates an Automatic Cross Pol Test
M_ACP
M_ACP
Initiates a Manual Cross Pol Test
S_ACP
S_ACP
Stops any Cross Pol testing in progress
INFO
ID (Value)
States the Controller ID
HW (Value)
States the Controller Board Hardware Type
SQ_T (Value)
Signal Quality Threshold for proper Controller SNR Reading
CC1
FBV (FW – BL)
States the Firmware and Boot loader version respectively
MA (Address)
States the Controller MAC Address
CC2
CONF_ID(Value)
States the Controller Configuration ID (for internal use)
DVB
DVB
States the DVB Mode in Use
MOD
SN (Value)
States the modem Serial Number
S (Status)
States the status of the modem
V (Version)
States the Modem Firmware Version
ERR
Error (Code)
Displays error codes if applicable
