10.2. Appendix 2: LCD Interface Table Summary
Menu Field Explanation
MONITOR
E (Angle)
Elevation Angle and Limit Indicators
A (Angle)
Azimuth Angle and Stow Limit Indicator
P (Angle)
P (Angle) – Polarization Angle and Stow Limit Indicator
ST
System Status
RF (Value)
RF (U/L) – Receive RF Signal Value and Lock/Unlock Status
GPS and CMPS
GPS Status Flag and Compass Status Flag
MAIN
M (SNR) D/E
Modem Signal and Transmitter Status
E (Angle)
Real Time Elevation Angle and Status
I/S
Real Time Current being drawn from the elevation motor @ the set speed
S (Value)
Elevation search window limit
Ad (Value)
Advanced Search Elevation Gap
EL
O (Value)
Elevation Offset used to obtain an accurate elevation reading
A (Angle)
Real Time Azimuth Angle and Status
I/S
Real Time Current drawn from the Azimuth motor @ the set speed
W (Value)
Azimuth search window limit
AZ
ZF
AZ Pot Zero and AZ Pot Factor for A/D to angle conversions of the AZ axis
P (Angle)
Real Time Polarization Angle and Status
I/S
Real Time Current drawn from the Polarization motor @ the set speed
O (Value)
Polarization offset
PL
ZF
PL Pot Zero and PL Pot Factor for A/D to angle conversions of the PL axis
GPS (Status)
GPS Status (i.e. Normal, Overridden, or Failure)
LAT and LONG
Latitudinal and Longitudinal GPS Coordinates
V (Value)
GPS Velocity – indication of moving vehicle
GPS
H (Value)
GPS Heading
CP (Status)
Compass Status (i.e. Normal, Overridden, or Failure)
H (Value)
Compass Heading taken after compass has been checked
CP_EL (Value)
Elevation angle at which the compass reading is taken
CP
V (Angles)
Compass headings after checking the compass
FREQUENCY
Transponder Frequency that DVB searches
SYMBOL RATE
Transponder Symbol Rate that DVB searches
CODE RATE
Transponder FEC (Code) Rate that DVB searches
LNB_P
Power supplied to the LNB when searching for target satellite
Ref Frequency
Reference Satellite Transponder Frequency that DVB searches
Ref sym rate
Reference Satellite Transponder Symbol Rate that DVB searches
Ref code rate
Reference Satellite Transponder FEC (Code) Rate that DVB searches
DVB
LNB_P (Ref)
LNB Power supplied to the LNB when searching for reference satellite
Sat Longitude
Target Satellite Locations Longitudinal Value and Hemisphere
Ref Sat
Longitude
Reference Satellite Longitudinal Value and Hemisphere
E (Value)
Target Antenna Elevation Value for Satellite acquisition
SAT
A (Value)
Target Antenna Azimuth Value for Satellite acquisition with reference to True North
