iNetVu™ 7000 Controller User Manual
Revision 1.19
10.1. Appendix 1: Default Limits and Configuration Data Tables
Compass Reading Elevation
PLATFORM TYPES
A1800A
/B/C/D
A1200C
A0980B A0740B A0660A
COMPASS READING
ELEVATION
32 32 35 25 25
Table 1: Compass Reading Elevation Default Values
Elevation Offset
PLATFORM TYPES
A1800A/
B/C/D
A1200P
A1200C
A0980B A0740B A0660A
EL OFFSET 45.00 31.00 42.00 31.00 31.00 35.00
Table 2: Default Elevation Offsets. All values are + 2  after Target Calibration.
AZ Potentiometer
PLATFORM TYPES
A1800A/
B/C/D
A1200P A1200C A0980B A0740B A0660A
AZ POT ZERO 280.7808 140.5 282.88 342.17 342.17 342.17
AZ POT FACTOR 0.5484 0.2746 0.5525 0.6683 0.6683 0.6683
Table 3: Azimuth Potentiometer Default Values
PL Potentiometer
PLATFORM TYPES
A1800A/
B/C/D
A1200P A1200C A0980B A0740B A0660A
PL POT ZERO 205.4144 190.7 197.22 131.79 131.79 131.79
PL POT FACTOR 0.4012 0.3726 0.3852 0.2574 0.2574 0.2574
Table 4: Polarization Potentiometer Default Values
